KS-5032H
페이지 정보
3,585 2016.09.08 11:05
첨부파일
본문
-
- E-Map Two-Way Audio
- High Quality Recording Resolution
- Video Codec
(H.264) - Simultaneous Display & Playback
- Smart Phone Support
- DDNS Support
Feature
- High Quality Recording Resolution at 4CIF
- MPEG-4, H.264 Codec Compression
- Simultaneous Multi-Channel Display & Playback
- Pentaplex (Live Monitoring, Recording, Playback , Transmission & Backup)
- Remote Monitoring, Playback, Backup & Setup through Network
- E-Map and Smart HDD Monitoring
- Various language support (Korean,English,Chinese,Japan,Russian,Spanish)
- User Friendly GUI and Easy Setup Router ( DDNS Support )
- Remote Monitoring by Remote Software and CMS
- Alarm in case of Motion Detection/System Start/Stop ( Option )
Main Functions
- Quick, Panorama, Smart Search & Snapshot, Bookmark, Digital Zoom Search, Thumbnail Search
- VDB & AVI, MP4, JPG, BMP, PNG Backup, Real-time network backup, massive NAS backup
- Various Data Backup Devices ( CD, DVD-RW & USB 2.0 port supported )
- Various Screen Division Mode , Display & TV-OUT Rotation, OSD ( On Screen Display )
- Channel Screen Covert and Channel Swapping
- PTZ (PAN /TILT /ZOOM /FOCUS /IRIS /AUTO PANNING /PRESET), RS-232, RS-485, Network Interface
- PTZ Auto Touring Schedule & Privacy Masking Support
- Motion Detection, Camera & Sensor & Relay connection Control support.
- Powerful Event Log Information Search ( Status Search by Each System, Network, Event & User )
- Two-Way Audio, PTZ Controller(Joystic) Support
- Emergency & Intensive Recording
Specification
| Model | KS-5032H |
|---|---|
| CPU | Dual Core |
| HDD | MAX 6 HDD (5 HDD + DVD-RW) |
| Analog Out | SPOT(RCA) |
| O / S | Windows 7 |
| Video In | 32CH |
| Video Output | RGB(VGA) DVI or HDMI |
| Audio In/ Out ( Option ) | Default:16, Option:32 / 1 |
| Backup | CD-RW, DVD-RW, USB HDD, USB CD-RW |
| Channel | 1/4/6/8/9/10/13/16/25/33, Auto Rotation |
| Display | Real-Time |
| Recording Speed | 960 fps 800 fps |
| Resolution | 352x240, 704x240, 704x480 |
| Compression Method | MPEG-4, H.264 |
| Compression Size | 352*240(1~5KB), 704*240(2~10KB), 704*480(4~20KB) |
| Recording Mode | Scheduled / Continuous / Motion Detection / Sensor / Sensor & Motion Detection |
| Sensor / Relay | 16 / 16 |
| PTZ Control & Port | PAN / TILT / ZOOM / FOCUS / AUX Control / LIGHT Control |
| Remote Transmission | Live Monitoring, Playback, File Saving and Event Notification |
| Remote Control | PTZ Control, Emergency Recording and Sensor In / Out |
| Network | 10/100 / 1000 BASE TX ETHERNET |
| Storage Temp. / Humidity | -20 ~ 60`C / 20 ~ 95 % RH |
| Operation Temp. / Humidity | -5 ~ 40`C / 20 ~ 80 % RH |
| Power | AC100~200V 2A / AC200~240V, 50/60HZ |
| Dimension / Weight | 440mm(W)x175mm(H)x500mm(D) / 15kg |
제품 모델에 따라 후면 입출력 단자는 다를 수 있습니다.
